Access Control Tripod Turnstile Security Systems With Ticket Inspection

Access Control Tripod Turnstile Security Systems With Ticket Inspection

Main Function and Features

1)Rapid identification technique, available to identify accurately and efficiently the magnetic card, bar code card, ID card and IC card.

2)With normally open & normally closed working mode

3)Real time failure self-detect and alarm indication, ensuring system safe operation and facilitating maintenance and operation.

4)With direction indication, guiding passenger to entry and exit.

5)Automatic counting and displaying number of passenger, facilitating observation and with a displaying total amount as high as 90,000. (Optional)

6)Sound (Light is optional) alarm indication function, preventing illegal entry or irregular passing.

7)Powerful on-line intelligent control mode, facilitating you:

A)To adjust the speed of operation of the barrier according to the flow of passenger and improve the passing rate.

B)To set up operation mode for passage entry and exit.

C)To read a card of multiple times, the special function meeting the application requirements of a particular site.

D)To set up the card reading with or without memory.

E)To select a reasonable normally open or close mode, to divert effectively the flow of passengers.

F)  To have humanized setting function for reset of over time passing.

8)  After the system power is cut off, the plate barrier starts the standby power to withdraw the barrier, so that the passage is ensured to be smooth and to divert the flow of passenger timely.

9)  The infrared sensing technique realizes real time monitor of passage, safe protection and tail-proof.

10)  The treatment mode in emergency or in special conditions.

11)  Having standard input/output port, facilitating the integration of the system and the other equipment, available for far end control and management.

12)  Super strong combination capability, with the combined application of products of different passage types and series, not affecting the system performance.

13)  Strong system expending capability, available to add new product at any time.

14)  Far end control management: function to far end control of barrier mode, meeting the special requirements of the users and the fire protection.reader.

Main Technical Specifications

  Operation voltage: AC220V (50Hz) /AC110 (60Hz)/ AC100-230V (50/60HZ)

  Driven motor: flap barrier 24V/30W;swing gate 24V/20W;

  Communications port and distance: RS485 electric device standard, ≤1200m

  Control panel with count and LED digital function

  Control panel with alarm and sounds indication functions

  Transit speed: 30 persons per minute (normally close mode); 50 persons per minute (normally open mode)

  Work environment: Indoor/Out door (with rain-tent cover)

  Temperature: -20 ℃ degree to 60 ℃

  Emergency and Traffic-light function

  Passage width: falp barrier≤600mm; swing gate600mm~900mm;
