| Material: | ABS | Color: | Black |
|---|---|---|---|
| Reaction Time: | 10ms | Sensitivity: | Adjustable |
| Dimension: | 27*21*37 Mm | Gross Weight: | 10g |
Small And Easy Install Traffic Loop Detectors For Gate , Sensitivity Adjustable
Introduction:
VD108B Loop detector is the smallest vehicle single loop detector, special design for controll board
of parking barrier gate. Simple and easy install. The sensitivity is adjust by the number of loop circle, can't change by DIP setting.
Application:
Parking Guidance System
Car Locating System
Parking Management system
Tragically
Product Features:
High temperature stability, used in kinds of environment
Environment drifting compensate automatically
Multilevel lightning protection
With function of sensing loop malfunction automatically (disconnection or cutting-out)
Cooperate with barrier gate to realize vehicle anti-hit and automatic close function
Specifications:
|
Supply Voltage |
DC 7V-12V 200mA |
|
Frequency range |
29 KHz-90 KHz |
|
Loop inductance |
80uH-300 uH |
|
Communication |
TTL |
|
Power supply |
DC 7-12v |
|
Temperature/Humidity |
Operation: -20-65°C/0-90%RH(Non-condensing) Storage: -40--85°C/0-90%RH(Non-condensing) |
|
Dimension |
27*21*37mm |
|
Weight |
10g |
