IVD -600 Dual Loop Detector For Automated Gates , 20ms Reaction Time

Large Image : IVD -600 Dual Loop Detector For Automated Gates , 20ms Reaction Time

Product Details:

Place of Origin:	Shenzhen,China
Brand Name:	Integer
Certification:	ISO 9001:2008,CE,Rohs
Model Number:	IVD-600

Payment & Shipping Terms:

Minimum Order Quantity:	1 pcs
Price:	USD0~30 per pcs
Packaging Details:	10070118 mm (L x W x H)
Delivery Time:	2~3 working days
Payment Terms:	T/T
Supply Ability:	10000pcs per month

Detailed Product Description

Material:	ABS	Color:	Black And Earth Yellow
Reaction Time:	20ms	Frequency Range::	20 KHz To 170 KHz
Dimension:	10070118 Mm	Gross Weight:	460g
Sensitivity:	10 Grade	Installation:	DIN Rail
Channel:	Double	Connection:	11 Pin Stock

IVD -600 Dual Loop Detector For Automated Gates , 20ms Reaction Time

Specifications:

Compatible with parking management system
Easy installation and operation
Factory price and fast shipping

Introduction:

double vehicle loop detector is used for wherever vehicles have to detected.
For example for monitoring and safe-guarding accessways or for counting vehicles.
The output singnal can be used for controlling door and barrier gate drive mechanisms, operation barriers, controlling traffic light system or activaticing card dispensers in parking management system.
IVD-600 connects two indutive loop (double channel)

Feature:
High temperature stability, used in kinds of environment
Enviorment drifting compensate automatically
With adjustable mulltievel sensitivity
User can choose working frequency according to real need
With two relay output
Small size take up little space

Technical Parameter:

Dimmesions: L110mm x W60mm x H100 mm (Double channel)
Power supply: DC12V/DC24V or AC220V/AC110V for optional
Power consumption: 5W as default
Output Mode: realy output
Operating temerature: -30 degree to 70 degree
Operating frequency: 20KHz to 170KHz
Installation: DIN lead rail
Connection: 11-PIN socket
Loop connecton wiring: max x 100m, twisted at least 20 times per meter
Total resistance: less than 10ohm
Automatic calibaration time: 2s to 5s
Reatiction time: 20ms (fastest) double channel
10ms (fastest) single channel
Shell: PC+ABS engineering plastivs
Net weight: 400g

IVD -600 Dual Loop Detector For Automated Gates , 20ms Reaction Time
