ABS Traffic Road Vehicle Double Loop Detector 20 Khz - 170 Khz

ABS Traffic Road Vehicle Double Loop Detector 20 Khz - 170 Khz

keywords:

loop detector wire, double loop detector, vehicle loop detector, radiation detector, loop, alarm lamp,

 inductive loop detector, gate loop detector, single loop detector, digital loop detector

Features:

1. Easy use and install

2. low price

3. Comply with parking system

Tr affic Road Car Vehicle Double Loop Detector Specifications

1.  Supply voltage AC: 220V, 110V, 24V, 12V

2.  Supply voltage DC: 24V, 12V

3.  Sensitivity: Adjustable in 3 increments (high .medium. low)

4.  Operating temperature: -20°C to +65°C

5.  Storage temperature: -40°C to +85°C

6.  Frequency range: 20 kHz to 170 kHz

7.  Reaction time: 100ms

8.  Loop inductance:

9.  Loop connection: <5m optimal

10.  Loop connection wiring: Maximum length 200 meters,twisted at least 20 times per meter

11.  Dimensions:100*70*118 mm (L x W x H)

12.  Net Weight: 400g

13. Frequency:the frequency can be altered by means of DIP6-Switch.

u to eliminate interference of two neighboring wire loops

u to eliminate interference of two neighboring loop detectors

u to eliminate interference of two neighboring distribution cables (loop detectors)

Attention:

When using more than 2 Detectors, please select different frequencies ,and screened cables for

Detector or connecting cables widely separated

Technical Parameter:

Power supply: DC12V/DC24V or AC220V/AC110V for optional
Power consumption: 5W as default
Output Mode: relay output
Operating temerature: -30 degree to 70 degree
Operating frequency: 20KHz to 170KHz
Installation: DIN lead rail
Connection: 11-PIN socket
Loop connecton wiring: max x 100m, twisted at least 20 times per meter
Total resistance: less than 10ohm
Automatic calibaration time: 2s to 5s
Reatiction time: 20ms (fastest) double channel
Shell: PC+ABS engineering plastivs
Net weight: 400g
